| ROTARY SCREW COMPRESSOR SERVICE |
#AIRCOMPRESSORS
#AIRCOMPRESSOR SERVICE
#INDUSTRIALCOMPRESSORS
WE SERVICE THE FOLLOWING ROTARY SCREW COMPRESSORS:
CURTIS ROTARY SCREW COMPRESSORS
CHAMPION ROTARY SCREW COMPRESSORS
INGERSOLL RAND ROTARY SCREW COMPRESSORS
JENNY
DAVEY ROTARY SCREW COMPRESSORS
ATLAS COPCO ROTARY SCREW COMPRESSORS
QUINCY ROTARY SCREW COMPRESSORS
SULLAIR ROTARY SCREW COMPRESSORS
Nx 4-15 kW Features
dBA SHIELD NOISE REDUCTION
Designed for quiet operation.
The ultimate in system protection and reliability.
Built to the highest levels of dependability and reliability.
Designed for low cost of ownership and easy service.
FS-Curtis backs the Nx products with first in industry extended warranty. The major components such as electric motor, separator tank, air/oil cooler and VFD/controller are covered by a full non-prorated 5 year and our airends are covered for a full 10 year of peace of mind coverage.
 |
| ROTARY SCREW COMPRESSORS |
Smart & Sophisticated Nx Series 4-15kW
NX SERIES: 5HP - 350HP ROTARY SCREW COMPRESSORS
4-15kW FIXED SPEED (VARIABLE SPEED AVAILABLE IN 8-15KW)
 |
| ROTARY SCREW COMPRESSORS |
THE BEST RATED ROTARY SCREW COMPRESSORS ON THE MARKET WITH THE BEST
EXTENDED WARRANTY PROGRAM. CURTIS…#1 CUSTOMER SATISFACTION.
 |
| INDUSTRIAL AIR COMPRESSORS |
The Nx’s smooth, quite operation is perfect for a wide variety of applications ranging from auto body shops to light industrial.
WE SERVICE THE FOLLOWING ROTARY SCREW COMPRESSORS:
CURTIS ROTARY SCREW COMPRESSORS
CHAMPION ROTARY SCREW COMPRESSORS
INGERSOLL RAND ROTARY SCREW COMPRESSORS
JENNY
DAVEY ROTARY SCREW COMPRESSORS
ATLAS COPCO ROTARY SCREW COMPRESSORS
QUINCY ROTARY SCREW COMPRESSORS
SULLAIR ROTARY SCREW COMPRESSORS
 |
| #AIRCOMPRESSORSERVICE |
Nx 4-15 kW Features
dBA SHIELD NOISE REDUCTION
Designed for quiet operation.
- Integration of centrifugal blower and drive motors make for extremely smooth and quiet operation
- Extra-thick sound insulation reduces noise
- Can be installed in applications where a quiet setting is important
The ultimate in system protection and reliability.
- Protects critical components from compressor-generated heat
- Extends component life and reduces downtime
- Compartmentalized air flow design and standard aftercooler
 |
| ROTARY SCREW COMPRESSOR SERVICE |
ROTARY SCREW
MAINTENANCE
ROTARY SCREW SERVICE
ROTARY SCREW REPAIR
 |
| AIR COMPRESSOR SERVICE |
Built to the highest levels of dependability and reliability.
- Standard TEFC motor protects compressor from surrounding dirty air, increasing the efficiency and proloning the life of the motor.
- Spin-on air/oil separator allows for quick maintenance and results in one-to-three PPM oil carryover. This translates into lower maek-oup oil costs and higher quality compressor air. This
translates into lower make-up oil costs and higher quality compressed air.
Designed for low cost of ownership and easy service.
 |
| AIR COMPRESSOR SERVICE |
- Space-saving design
- Pulsation-free air
- 100% continuous duty
- Extended service intervals
- More CFM per horsepower
- Improved air quality
- Energy efficiency at full load delivers more air for the mone integrated into a smaller footprint
- Exclusive FS-Curtis airends utilize the latest rotor profile to maximize efficiency
- The VSD - time proven directly coupled design - offers faster response and greater operational efficiency
- Variable operation slows airend speed, which lowers energy costs and reduces wear
- With DemandSmart technology, the VSD enhances quality by stabilizing air pressure at 1 psi increments
- Built-in DC Choke protects against harmonic disturbances and eliminates the need to source additional corrective devices
 |
| AIR COMPRESSOR REPAIR |
FS-Curtis backs the Nx products with first in industry extended warranty. The major components such as electric motor, separator tank, air/oil cooler and VFD/controller are covered by a full non-prorated 5 year and our airends are covered for a full 10 year of peace of mind coverage.
 |
| AIR COMPRESSOR SERVICE |
LOOKING FOR ROTARY SCREW COMPRESSOR PARTS?
ROTARY SCREW SEPARATORS
ROTARY SCREW OIL
ROTARY SCREW FILTERS
ROTARY SCREW TEMP. SENSORS
ROTARY SCREW PRESSURE SWITCHES
ROTARY SCREW MIN. PRESSURE VALVES
ROTARY SCREW BELTS
ROTARY SCREW HOSES
ROTARY SCREW MOTORS
ROTARY SCREW AIR ENDS
ROTARY SCREW CONTROL PANELS
ROTARY SCREW SENSORS
 |
| AIR COMPRESSOR SERVICE |
CALL: 214-428-2868
| Model | HP | VOLT | PSI | CFM | Part Number |
| NxB30 | 40 | 230 | 100 | 196 | FNB30DXX3HXXX |
| NxB30 | 40 | 460 | FNB30DXX4HXXX | ||
| NxB30 | 40 | 230 | 125 | 173 | FNB30DXX3JXXX |
| NxB30 | 40 | 460 | FNB30DXX4JXXX | ||
| NxB30 | 40 | 230 | 150 | 163 | FNB30DXX3KXXX |
| NxB30 | 40 | 460 | FNB30DXX4KXXX | ||
| NxB30 | 40 | 230 | 175 | 149 | FNB30DXX3LXXX |
| NxB30 | 40 | 460 | FNB30DXX4LXXX | ||
| NxB37 | 50 | 230 | 100 | 234 | FNB37DXX3HXXX |
| NxB37 | 50 | 460 | FNB37DXX4HXXX | ||
| NxB37 | 50 | 230 | 125 | 203 | FNB37DXX3JXXX |
| NxB37 | 50 | 460 | FNB37DXX4JXXX | ||
| NxB37 | 50 | 230 | 150 | 193 | FNB37DXX3KXXX |
| NxB37 | 50 | 460 | FNB37DXX4KXXX | ||
| NxB37 | 50 | 230 | 175 | 180 | FNB37DXX3LXXX |
| NxB37 | 50 | 460 | FNB37DXX4LXXX | ||
| NxB30 | 40 | 230 | 100 | 196 | FNB30DXD3HXXX |
| NxB30 | 40 | 460 | FNB30DXD4HXXX | ||
| NxB30 | 40 | 230 | 125 | 173 | FNB30DXD3JXXX |
| NxB30 | 40 | 460 | FNB30DXD4JXXX | ||
| NxB30 | 40 | 230 | 150 | 163 | FNB30DXD3KXXX |
| NxB30 | 40 | 460 | FNB30DXD4KXXX | ||
| NxB30 | 40 | 230 | 175 | 149 | FNB30DXD3LXXX |
| NxB30 | 40 | 460 | FNB30EXD4LXXX | ||
| NxB37 | 50 | 230 | 100 | 234 | FNB37DXD3HXXX |
| NxB37 | 50 | 460 | FNB37DXD4HXXX | ||
| NxB37 | 50 | 230 | 125 | 203 | FNB37DXD3JXXX |
| NxB37 | 50 | 460 | FNB37DXD4JXXX | ||
| NxB37 | 50 | 230 | 150 | 193 | FNB37DXD3KXXX |
| NxB37 | 50 | 460 | FNB37DXD4KXXX | ||
| NxB37 | 50 | 230 | 175 | 180 | FNB37DXD3LXXX |
| NxB37 | 50 | 460 | FNB37DXD4LXXX |
 |
| AIR COMPRESSOR SERVICE |
H&K AIR COMPRESSORS
214-428-2868
 |
| ROTARY SCREW COMPRESSOR OIL |
| MODEL | HP | VOLT | PSI | CFM | PART NUMBER |
| NxV45 | 60 | 460 | 100 | 288.3-63.5 | FNV45EXX4HXPC |
| NxV45 | 60 | 460 | 125 | 262.7-70.5 | FNV45EXX4JXPC |
| NxV45 | 60 | 460 | 150 | 244.7-64.2 | FNV45EXX4KXPC |
| NxV55 | 75 | 460 | 100 | 345.4-71.3 | FNV55EXX4HXPC |
| NxV55 | 75 | 460 | 125 | 314.2-94.0 | FNV55EXX4JXPC |
| NxV55 | 75 | 460 | 150 | 277.4-122.3 | FNV55EXX4KXPC |
| NxV75 | 100 | 460 | 100 | 498.8-120.7 | FNV75FXX4HXPC |
| NxV75 | 100 | 460 | 125 | 450.8-119.7 | FNV75FXX4JXPC |
| NxV75 | 100 | 460 | 150 | 411.3-117.4 | FNV75FXX4KXPC |
| NxV90 | 125 | 460 | 100 | 567.3-120.7 | FNV90FXX4HXPC |
| NxV90 | 125 | 460 | 125 | 505.5-119.7 | FNV90FXX4JXPC |
| NxV90 | 125 | 460 | 150 | 456.5-117.5 | FNV90FXX4KXPC |
| NxV110 | 150 | 460 | 100 | * | FNV110GXX4HXPC |
| NxV110 | 150 | 460 | 125 | * | FNV110GXX4JXPC |
| NxV110 | 150 | 460 | 150 | * | FNV110GXX4KXPC |
| NxV160 | 200 | 460 | 115 | * | FNV160HXX4JXPC |
| NxV185 | 250 | 460 | 115 | * | FNV185HXX4JXPC |
| RS SERIES | 15 | 460 | 100 | 69 | FRB15FUXXA4H1XXXX |
| RS SERIES | 15 | 460 | 125 | 59 | FRB15FUXXA4J1XXXX |
| RS SERIES | 15 | 460 | 150 | 51 | FRB15FUXXA4K1XXXX |
| RS SERIES | 15 | 460 | 175 | 45 | FRB15FUXXA4L1XXXX |
| RS SERIES | 20 | 460 | 100 | 92 | FRB20FUXXA4H1XXXX |
| RS SERIES | 20 | 460 | 125 | 81 | FRB20FUXXA4J1XXXX |
| RS SERIES | 20 | 460 | 150 | 76 | FRB20FUXXA4K1XXXX |
| RS SERIES | 20 | 460 | 175 | 65 | FRB20FUXXA4L1XXXX |
| RS SERIES | 25 | 460 | 100 | 111 | FRB25FUXXA4H1XXXX |
| RS SERIES | 25 | 460 | 125 | 104 | FRB25FUXXA4J1XXXX |
| RS SERIES | 25 | 460 | 150 | 92 | FRB25FUXXA4K1XXXX |
| RS SERIES | 25 | 460 | 175 | 84 | FRB25FUXXA4L1XXXX |
| RS SERIES | 30 | 460 | 100 | 135 | FRB30FUXXA4H1XXXX |
| RS SERIES | 30 | 460 | 125 | 129 | FRB30FUXXA4J1XXXX |
| RS SERIES | 30 | 460 | 150 | 115 | FRB30FUXXA4K1XXXX |
| RS SERIES | 30 | 460 | 175 | 102 | FRB30FUXXA4L1XXXX |
| RS SERIES | 40 | 460 | 100 | 189 | FRB40FUXXA4H1XXXX |
| RS SERIES | 40 | 460 | 125 | 173 | FRB40FUXXA4J1XXXX |
| RS SERIES | 40 | 460 | 150 | 150 | FRB40FUXXA4K1XXXX |
| RS SERIES | 40 | 460 | 175 | 140 | FRB40FUXXA4L1XXXX |
| RS SERIES | 50 | 460 | 100 | 220 | FRB50FUXXA4H1XXXX |
| RS SERIES | 50 | 460 | 125 | 200 | FRB50FUXXA4J1XXXX |
| RS SERIES | 50 | 460 | 150 | 186 | FRB50FUXXA4K1XXXX |
| RS SERIES | 50 | 460 | 175 | 170 | FRB50FUXXA4L1XXXX |
| RS SERIES | 15 | 460 | 100 | 69 | FRB15FU8XA4H1XXXX |
| RS SERIES | 15 | 460 | 125 | 59 | FRB15FU8XA4J1XXXX |
| RS SERIES | 15 | 460 | 150 | 51 | FRB15FU8XA4K1XXXX |
| RS SERIES | 15 | 460 | 175 | 45 | FRB15FU8XA4L1XXXX |
| RS SERIES | 20 | 460 | 100 | 92 | FRB20FU1XA4H1XXXX |
| RS SERIES | 20 | 460 | 125 | 81 | FRB20FU1XA4J1XXXX |
| RS SERIES | 20 | 460 | 150 | 76 | FRB20FU1XA4K1XXXX |
| RS SERIES | 20 | 460 | 175 | 65 | FRB20FU1XA4L1XXXX |
| RS SERIES | 25 | 460 | 100 | 111 | FRB25FU1XA4H1XXXX |
| RS SERIES | 25 | 460 | 125 | 104 | FRB25FU1XA4J1XXXX |
| RS SERIES | 25 | 460 | 150 | 92 | FRB25FU1XA4K1XXXX |
| RS SERIES | 25 | 460 | 175 | 84 | FRB25FU1XA4L1XXXX |
| RS SERIES | 30 | 460 | 100 | 135 | FRB30FU1XA4H1XXXX |
| RS SERIES | 30 | 460 | 125 | 129 | FRB30FU1XA4J1XXXX |
| RS SERIES | 30 | 460 | 150 | 115 | FRB30FU1XA4K1XXXX |
| RS SERIES | 30 | 460 | 175 | 102 | FRB30FU1XA4L1XXXX |
| RS SERIES | 40 | 460 | 100 | 189 | FRB40FU2XA4H1XXXXX |
| RS SERIES | 40 | 460 | 125 | 173 | FRB40FU2XA4J1XXXXX |
| RS SERIES | 40 | 460 | 150 | 150 | FRB40FU2XA4K1XXXXX |
| RS SERIES | 40 | 460 | 175 | 140 | FRB40FU2XA4L1XXXXX |
 |
| COMPRESSOR SERVICE |
| MODEL # | HP | Voltage | PSI | CFM | PART # |
| NxD75 | 100 | 460 | 100 | 495 | FND75FXX4HXPC |
| NxD75 | 100 | 575 | FND75FXX8HXPC | ||
| NxD75 | 100 | 460 | 125 | 437 | FND75FXX4JXPC |
| NxD75 | 100 | 575 | FND75FXX8JXPC | ||
| NxD75 | 100 | 460 | 150 | 416 | FND75FXX4KXPC |
| NxD75 | 100 | 575 | FND75FXX8KXPC | ||
| NxD75 | 100 | 460 | 175 | 382 | FND75FXX4LXPC |
| NxD75 | 100 | 575 | FND75FXX8LXPC | ||
| NxD90 | 125 | 460 | 100 | 553 | FND90FXX4HXPC |
| NxD90 | 125 | 575 | FND90FXX8HXPC | ||
| NxD90 | 125 | 460 | 125 | 492 | FND90FXX4JXPC |
| NxD90 | 125 | 575 | FND90FXX8JXPC | ||
| NxD90 | 125 | 460 | 150 | 448 | FND90FXX4KXPC |
| NxD90 | 125 | 575 | FND90FXX8KXPC | ||
| NxD90 | 125 | 460 | 175 | 424 | FND90FXX4LXPC |
| NxD90 | 125 | 575 | FND90FXX8LXPC | ||
| NxD110 | 150 | 460 | 125 | 622 | FND110GXX4JXPC |
| NxD160 | 200 | 460 | 125 | 938 | FND160HXX4JXPC |
| NxD185 | 250 | 460 | 125 | 1029 | FND185HXX4JXPC |
| NxHE90 | 125 | 460 | 125 | 632 | FHE90GXX4JXPC |
| NxHE110 | 150 | 460 | 125 | 755 | FHE110GXX4JXPC |
| NxHE132 | 175 | 460 | 125 | 904 | FHE132GXX4JXPC |
| NxHE160 | 200 | 460 | 125 | 1119 | FHE160HXX4JXPC |
| NxHE185 | 250 | 460 | 125 | 1267 | FHE185HXX4JXPC |
| NxHE200 | 275 | 460 | 125 | 1373 | FHE200IXX4JXPC |
| NxHE220 | 300 | 460 | 125 | 1507 | FHE220IXX4JXPC |
| NxHE260 | 350 | 460 | 125 | 1748 | FHE260IXX4JXPC |
| NxV08 | 10 | 460 | 100 | 45-17 | FNV08B8X4HXPC |
| NxV08 | 10 | 460 | 125 | 42-17 | FNV08B8X4JXPC |
| NxV08 | 10 | 460 | 150 | 33-17 | FNV08B8X4KXPC |
| NxV08 | 10 | 460 | 175 | 25-16 | FNV08B8X4LXPC |
| NxV11 | 15 | 460 | 100 | 63-17 | FNV11B8X4HXPC |
| NxV11 | 15 | 460 | 125 | 58-17 | FNV11B8X4JXPC |
| NxV11 | 15 | 460 | 150 | 50-16 | FNV11B8X4KXPC |
| NxV11 | 15 | 460 | 175 | 44-16 | FNV11B8X4LXPC |
| NxV15 | 20 | 460 | 100 | 82-17 | FNV15B8X4HXPC |
| NxV15 | 20 | 460 | 125 | 77-17 | FNV15B8X4JXPC |
| NxV15 | 20 | 460 | 150 | 72-17 | FNV15B8X4KXPC |
| NxV15 | 20 | 460 | 175 | 60-16 | FNV15B8X4LXPC |
| NxV08 | 10 | 460 | 100 | 45-17 | FNV08BXX4HXPC |
| NxV08 | 10 | 460 | 125 | 42-17 | FNV08BXX4JXPC |
| NxV08 | 10 | 460 | 150 | 33-17 | FNV08BXX4KXPC |
| NxV08 | 10 | 460 | 175 | 25-16 | FNV08BXX4LXPC |
| NxV11 | 15 | 460 | 100 | 63-17 | FNV11BXX4HXPC |
| NxV11 | 15 | 460 | 125 | 58-17 | FNV11BXX4JXPC |
| NxV11 | 15 | 460 | 150 | 50-16 | FNV11BXX4KXPC |
| NxV11 | 15 | 460 | 175 | 44-16 | FNV11BXX4LXPC |
| NxV15 | 20 | 460 | 100 | 82-17 | FNV15BXX4HXPC |
| NxV15 | 20 | 460 | 125 | 77-17 | FNV15BXX4JXPC |
| NxV15 | 20 | 460 | 150 | 72-17 | FNV15BXX4KXPC |
| NxV15 | 20 | 460 | 175 | 60-16 | FNV15BXX4LXPC |
| NxV18 | 25 | 460 | 100 | 112-33 | FNV18C1X4HXPC |
| NxV18 | 25 | 460 | 125 | 102-33 | FNV18C1X4JXPC |
| NxV18 | 25 | 460 | 150 | 91-44 | FNV18C1X4KXPC |
| NxV18 | 25 | 460 | 175 | 83-40 | FNV18C1X4LXPC |
| NxV22 | 30 | 460 | 100 | 129-34 | FNV22C1X4HXPC |
| NxV22 | 30 | 460 | 125 | 118-33 | FNV22C1X4JXPC |
| NxV22 | 30 | 460 | 150 | 112-32 | FNV22C1X4KXPC |
| NxV22 | 30 | 460 | 175 | 105-40 | FNV22C1X4LXPC |
| NxV18 | 25 | 460 | 100 | 112-33 | FNV18CXX4HXPC |
| NxV18 | 25 | 460 | 125 | 102-33 | FNV18CXX4JXPC |
| NxV18 | 25 | 460 | 150 | 91-44 | FNV18CXX4KXPC |
| NxV18 | 25 | 460 | 175 | 83-40 | FNV18CXX4LXPC |
| NxV22 | 30 | 460 | 100 | 129-34 | FNV22CXX4HXPC |
| NxV22 | 30 | 460 | 125 | 118-33 | FNV22CXX4JXPC |
| NxV22 | 30 | 460 | 150 | 112-32 | FNV22CXX4KXPC |
| NxV22 | 30 | 460 | 175 | 105-40 | FNV22CXX4LXPC |
| NxV30 | 40 | 460 | 100 | 183-52 | FNV30DXX4HXPC |
| NxV30 | 40 | 460 | 125 | 169-51 | FNV30DXX4JXPC |
| NxV30 | 40 | 460 | 150 | 153-50 | FNV30DXX4KXPC |
| NxV30 | 40 | 460 | 175 | 135-48 | FNV30DXX4LXPC |
| NxV37 | 50 | 460 | 100 | 227-52 | FNV37DXX4HXPC |
| NxV37 | 50 | 460 | 125 | 210-51 | FNV37DXX4JXPC |
| NxV37 | 50 | 460 | 150 | 189-50 | FNV37DXX4KXPC |
| NxV37 | 50 | 460 | 175 | 168-48 |
FNV37DXX4LXPC
|
 |
| AIR COMPRESSOR SERVICE |
ROTARY SCREW
MAINTENANCE
ROTARY SCREW SERVICE
ROTARY SCREW REPAIR
 |
| AIR COMPRESSOR SERVICE |
| Model | HORSEPOWER | VOLT | PSI | CFM | PART NUMBER | |
| NxB18 | 25 | 230 | 100 | 114 | FNB18C1X3HXXX | |
| NxB18 | 25 | 460 | FNB18C1X4HXXX | |||
| NxB18 | 25 | 230 | 125 | 100 | FNB18C1X3JXXX | |
| NxB18 | 25 | 460 | FNB18C1X4JXXX | |||
| NxB18 | 25 | 230 | 150 | 92 | FNB18C1X3KXXX | |
| NxB18 | 25 | 460 | FNB18C1X4KXXX | |||
| NxB18 | 25 | 230 | 175 | 84 | FNB18C1X3LXXX | |
| NxB18 | 25 | 460 | FNB18C1X4LXXX | |||
| NxB22 | 30 | 230 | 100 | 134 | FNB22C1X3HXXX | |
| NxB22 | 30 | 460 | FNB22C1X4HXXX | |||
| NxB22 | 30 | 230 | 125 | 116 | FNB22C1X3JXXX | |
| NxB22 | 30 | 460 | FNB22C1X4JXXX | |||
| NxB22 | 30 | 230 | 150 | 109 | FNB22C1X3KXXX | |
| NxB22 | 30 | 460 | FNB22C1X4KXXX | |||
| NxB22 | 30 | 230 | 175 | 95 | FNB22C1X3LXXX | |
| NxB22 | 30 | 460 | FNB22C1X4LXXX | |||
| NxB18 | 25 | 230 | 100 | 114 | FNB18CXX3HXXX | |
| NxB18 | 25 | 460 | FNB18CXX4HXXX | |||
| NxB18 | 25 | 230 | 125 | 100 | FNB18CXX3JXXX | |
| NxB18 | 25 | 460 | FNB18CXX4JXXX | |||
| NxB18 | 25 | 230 | 150 | 92 | FNB18CXX3KXXX | |
| NxB18 | 25 | 460 | FNB18CXX4KXXX | |||
| NxB18 | 25 | 230 | 175 | 84 | FNB18CXX3LXXX | |
| NxB18 | 25 | 460 | FNB18CXX4LXXX | |||
| NxB22 | 30 | 230 | 100 | 134 | FNB22CXX3HXXX | |
| NxB22 | 30 | 460 | FNB22CXX4HXXX | |||
| NxB22 | 30 | 230 | 125 | 116 | FNB22CXX3JXXX | |
| NxB22 | 30 | 460 | FNB22CXX4JXXX | |||
| NxB22 | 30 | 230 | 150 | 109 | FNB22CXX3KXXX | |
| NxB22 | 30 | 460 | FNB22CXX4KXXX | |||
| NxB22 | 30 | 230 | 175 | 95 | FNB22CXX3LXXX | |
| NxB22 | 30 | 460 | FNB22CXX4LXXX | |||
| NxB30 | 40 | 230 | 100 | 196 | FNB30DXX3HXXX | |
| NxB30 | 40 | 460 | FNB30DXX4HXXX | |||
| NxB30 | 40 | 230 | 125 | 173 | FNB30DXX3JXXX | |
| NxB30 | 40 | 460 | FNB30DXX4JXXX | |||
| NxB30 | 40 | 230 | 150 | 163 | FNB30DXX3KXXX | |
| NxB30 | 40 | 460 | FNB30DXX4KXXX | |||
| NxB30 | 40 | 230 | 175 | 149 | FNB30DXX3LXXX | |
| NxB30 | 40 | 460 | FNB30DXX4LXXX | |||
| NxB37 | 50 | 230 | 100 | 234 | FNB37DXX3HXXX | |
| NxB37 | 50 | 460 | FNB37DXX4HXXX | |||
| NxB37 | 50 | 230 | 125 | 203 | FNB37DXX3JXXX | |
| NxB37 | 50 | 460 | FNB37DXX4JXXX | |||
| NxB37 | 50 | 230 | 150 | 193 | FNB37DXX3KXXX | |
| NxB37 | 50 | 460 | FNB37DXX4KXXX | |||
| NxB37 | 50 | 230 | 175 | 180 | FNB37DXX3LXXX | |
| NxB37 | 50 | 460 | FNB37DXX4LXXX | |||
| NxD45 | 60 | 230 | FND45EXX3HXPC | |||
| NxD45 | 60 | 460 | 100 | 288 | FND45EXX4HXPC | |
| NxD45 | 60 | 575 | FND45EXX8HXPC | |||
| NxD45 | 60 | 230 | FND45EXX3JXPC | |||
| NxD45 | 60 | 460 | 125 | 263 | FND45EXX4JXPC | |
| NxD45 | 60 | 575 | FND45EXX8JXPC | |||
| NxD45 | 60 | 230 | FND45EXX3KXPC | |||
| NxD45 | 60 | 460 | 150 | 246 | FND45EXX4KXPC | |
| NxD45 | 60 | 575 | FND45EXX8KXPC | |||
| NxD45 | 60 | 230 | FND45EXX3LXPC | |||
| NxD45 | 60 | 460 | 175 | 223 | FND45EXX4LXPC | |
| NxD45 | 60 | 575 | FND45EXX8LXPC | |||
| NxD55 | 75 | 230 | FND55EXX3HXPC | |||
| NxD55 | 75 | 460 | 100 | 356 | FND55EXX4HXPC | |
| NxD55 | 75 | 575 | FND55EXX8HXPC | |||
| NxD55 | 75 | 230 | FND55EXX3JXPC | |||
| NxD55 | 75 | 460 | 125 | 324 | FND55EXX4JXPC | |
| NxD55 | 75 | 575 | FND55EXX8JXPC | |||
| NxD55 | 75 | 230 | FND55EXX3KXPC | |||
| NxD55 | 75 | 460 | 150 | 293 | FND55EXX4KXPC | |
| NxD55 | 75 | 575 | FND55EXX8KXPC | |||
| NxD55 | 75 | 230 | FND55EXX3LXPC | |||
| NxD55 | 75 | 460 | 175 | 270 | FND55EXX4LXPC | |
| NxD55 | 75 | 575 | FND55EXX8LXPC |
 |
| AIR COMPRESSOR SERVICE |
| BRAND | Model | HP | VOLT | PSI | CFM | Part Number |
| CURTIS | NxB08 | 10 | 230 | FNB08BXX3HXXX | ||
| CURTIS | NxB08 | 10 | 460 | 100 | 45 | FNB08BXX4HXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXX3JXXX | ||
| CURTIS | NxB08 | 10 | 460 | 125 | 42 | FNB08BXX4JXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXX3KXXX | ||
| CURTIS | NxB08 | 10 | 460 | 150 | 37 | FNB08BXX4KXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXX3LXXX | ||
| CURTIS | NxB08 | 10 | 460 | 175 | 33 | FNB08BXX4LXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXX3HXXX | ||
| CURTIS | NxB11 | 15 | 460 | 100 | 63 | FNB11BXX4HXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXX3JXXX | ||
| CURTIS | NxB11 | 15 | 460 | 125 | 58 | FNB11BXX4JXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXX3KXXX | ||
| CURTIS | NxB11 | 15 | 460 | 150 | 50 | FNB11BXX4KXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXX3LXXX | ||
| CURTIS | NxB11 | 15 | 460 | 175 | 45 | FNB11BXX4LXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXX3HXXX | ||
| CURTIS | NxB15 | 20 | 460 | 100 | 82 | FNB15BXX4HXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXX3JXXX | ||
| CURTIS | NxB15 | 20 | 460 | 125 | 77 | FNB15BXX4JXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXX3KXXX | ||
| CURTIS | NxB15 | 20 | 460 | 150 | 72 | FNB15BXX4KXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXX3LXXX | ||
| CURTIS | NxB15 | 20 | 460 | 175 | 62 | FNB15BXX4LXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXD3HXXX | ||
| CURTIS | NxB08 | 10 | 460 | 100 | 45 | FNB08BXD4HXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXD3JXXX | ||
| CURTIS | NxB08 | 10 | 460 | 125 | 42 | FNB08BXD4JXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXD3KXXX | ||
| CURTIS | NxB08 | 10 | 460 | 150 | 37 | FNB08BXD4KXXX |
| CURTIS | NxB08 | 10 | 230 | FNB08BXD3LXXX | ||
| CURTIS | NxB08 | 10 | 460 | 175 | 33 | FNB08BXD4LXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXD3HXXX | ||
| CURTIS | NxB11 | 15 | 460 | 100 | 63 | FNB11BXD4HXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXD3JXXX | ||
| CURTIS | NxB11 | 15 | 460 | 125 | 58 | FNB11BXD4JXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXD3KXXX | ||
| CURTIS | NxB11 | 15 | 460 | 150 | 50 | FNB11BXD4KXXX |
| CURTIS | NxB11 | 15 | 230 | FNB11BXD3LXXX | ||
| CURTIS | NxB11 | 15 | 460 | 175 | 45 | FNB11BXD4LXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXD3HXXX | ||
| CURTIS | NxB15 | 20 | 460 | 100 | 82 | FNB15BXD4HXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXD3JXXX | ||
| CURTIS | NxB15 | 20 | 460 | 125 | 77 | FNB15BXD4JXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXD3KXXX | ||
| CURTIS | NxB15 | 20 | 460 | 150 | 72 | FNB15BXD4KXXX |
| CURTIS | NxB15 | 20 | 230 | FNB15BXD3LXXX | ||
| CURTIS | NxB15 | 20 | 460 | 175 | 62 | FNB15BXD4LXXX |
 |
| ROTARY SCREW COMPRESSOR |
| Model | HP | OLT | PSI | CFM | Part Number |
| NxB08 | 10 | 230 | FNB08B8X3HXXX | ||
| NxB08 | 10 | 460 | 100 | 45 | FNB08B8X4HXXX |
| NxB08 | 10 | 230 | FNB08B8X3JXXX | ||
| NxB08 | 10 | 460 | 125 | 42 | FNB08B8X4JXXX |
| NxB08 | 10 | 230 | FNB08B8X3KXXX | ||
| NxB08 | 10 | 460 | 150 | 37 | FNB08B8X4KXXX |
| NxB08 | 10 | 230 | FNB08B8X3LXXX | ||
| NxB08 | 10 | 460 | 175 | 33 | FNB08B8X4LXXX |
| NxB11 | 15 | 230 | FNB11B8X3HXXX | ||
| NxB11 | 15 | 460 | 100 | 63 | FNB11B8X4HXXX |
| NxB11 | 15 | 230 | FNB11B8X3JXXX | ||
| NxB11 | 15 | 460 | 125 | 58 | FNB11B8X4JXXX |
| NxB11 | 15 | 230 | FNB11B8X3KXXX | ||
| NxB11 | 15 | 460 | 150 | 50 | FNB11B8X4KXXX |
| NxB11 | 15 | 230 | FNB11B8X3LXXX | ||
| NxB11 | 15 | 460 | 175 | 45 | FNB11B8X4LXXX |
| NxB15 | 20 | 230 | FNB15B8X3HXXX | ||
| NxB15 | 20 | 460 | 100 | 82 | FNB15B8X4HXXX |
| NxB15 | 20 | 230 | FNB15B8X3JXXX | ||
| NxB15 | 20 | 460 | 125 | 77 | FNB15B8X4JXXX |
| NxB15 | 20 | 230 | FNB15B8X3KXXX | ||
| NxB15 | 20 | 460 | 150 | 72 | FNB15B8X4KXXX |
| NxB15 | 20 | 230 | FNB15B8X3LXXX | ||
| NxB15 | 20 | 460 | 175 | 62 | FNB15B8X4LXXX |
| NxB08 | 10 | 230 | FNB08B8U3HXXX | ||
| NxB08 | 10 | 460 | 100 | 45 | FNB08B8U4HXXX |
| NxB08 | 10 | 230 | FNB08B8U3JXXX | ||
| NxB08 | 10 | 460 | 125 | 42 | FNB08B8U4JXXX |
| NxB08 | 10 | 230 | FNB08B8U3KXXX | ||
| NxB08 | 10 | 460 | 150 | 37 | FNB08B8U4KXXX |
| NxB08 | 10 | 230 | FNB08B8U3LXXX | ||
| NxB08 | 10 | 460 | 175 | 33 | FNB08B8U4LXXX |
| NxB11 | 15 | 230 | FNB11B8U3HXXX | ||
| NxB11 | 15 | 460 | 100 | 63 | FNB11B8U4HXXX |
| NxB11 | 15 | 230 | FNB11B8U3JXXX | ||
| NxB11 | 15 | 460 | 125 | 58 | FNB11B8U4JXXX |
| NxB11 | 15 | 230 | FNB11B8U3KXXX | ||
| NxB11 | 15 | 460 | 150 | 50 | FNB11B8U4KXXX |
| NxB11 | 15 | 230 | FNB11B8U3LXXX | ||
| NxB11 | 15 | 460 | 175 | 45 | FNB11B8U4LXXX |
| NxB15 | 20 | 230 | FNB15B8U3HXXX | ||
| NxB15 | 20 | 460 | 100 | 82 | FNB15B8U4HXXX |
| NxB15 | 20 | 230 | FNB15B8U3JXXX | ||
| NxB15 | 20 | 460 | 125 | 77 | FNB15B8U4JXXX |
| NxB15 | 20 | 230 | FNB15B8U3KXXX | ||
| NxB15 | 20 | 460 | 150 | 72 | FNB15B8U4KXXX |
| NxB15 | 20 | 230 | FNB15B8U3LXXX | ||
| NxB15 | 20 | 460 | 175 | 62 |
FNB15B8U4LXXX
|
 |
| AIR COMPRESSOR REPAIR |
| BRAND | MODEL | HP | Voltage | Pressure | CFM | PART # |
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXX2HXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 100 | 22 | FNB04AXX3HXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXX4HXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXX2JXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 125 | 20 | FNB04AXX3JXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXX4JXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXX2KXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 150 | 17 | FNB04AXX3KXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXX4KXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXX2LXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 175 | 15 | FNB04AXX3LXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXX4LXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXX2HXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 100 | 29 | FNB06AXX3HXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXX4HXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXX2JXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 125 | 27 | FNB06AXX3JXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXX4JXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXX2KXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 150 | 24 | FNB06AXX3KXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXX4KXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXX2LXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 175 | 22 | FNB06AXX3LXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXX4LXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXD2HXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 100 | 22 | FNB04AXD3HXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXD4HXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXD2JXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 125 | 20 | FNB04AXD3JXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXD4JXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXD2KXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 150 | 17 | FNB04AXD3KXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXD4KXXX | ||
| CURTIS | NxB04 | 5 | 230/1 | FNB04AXD2LXXX | ||
| CURTIS | NxB04 | 5 | 230/3 | 175 | 15 | FNB04AXD3LXXX |
| CURTIS | NxB04 | 5 | 460/3 | FNB04AXD4LXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXD2HXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 100 | 29 | FNB06AXD3HXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXD4HXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXD2JXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 125 | 27 | FNB06AXD3JXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXD4JXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXD2KXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 150 | 24 | FNB06AXD3KXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXD4KXXX | ||
| CURTIS | NxB06 | 7.5 | 230/1 | FNB06AXD2LXXX | ||
| CURTIS | NxB06 | 7.5 | 230/3 | 175 | 22 | FNB06AXD3LXXX |
| CURTIS | NxB06 | 7.5 | 460/3 | FNB06AXD4LXXX |
H&K AIR COMPRESSORS
214-428-2868
ROTARY SCREW
MAINTENANCE
ROTARY SCREW SERVICE
ROTARY SCREW REPAIR
 |
| AIR COMPRESSOR SERVICE |
#ROTARYSCREW
#ROTARYCOMPRESSORS
#LARGECOMPRESSORS
#ENERGYEFFICIENT
 |
| WWW.HKAIRCOMPRESSORS.COM |
| Model | HP | Voltage | Pressure | CFM | Part Number |
| NxB04 | 5 | 230/1 | FNB04A6X2HXXX | ||
| NxB04 | 5 | 230/3 | 100 | 22 | FNB04A6X3HXXX |
| NxB04 | 5 | 460/3 | FNB04A6X4HXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6X2JXXX | ||
| NxB04 | 5 | 230/3 | 125 | 20 | FNB04A6X3JXXX |
| NxB04 | 5 | 460/3 | FNB04A6X4JXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6X2KXXX | ||
| NxB04 | 5 | 230/3 | 150 | 17 | FNB04A6X3KXXX |
| NxB04 | 5 | 460/3 | FNB04A6X4KXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6X2LXXX | ||
| NxB04 | 5 | 230/3 | 175 | 15 | FNB04A6X3LXXX |
| NxB04 | 5 | 460/3 | FNB04A6X4LXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6X2HXXX | ||
| NxB06 | 7.5 | 230/3 | 100 | 29 | FNB06A6X3HXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6X4HXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6X2JXXX | ||
| NxB06 | 7.5 | 230/3 | 125 | 27 | FNB06A6X3JXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6X4JXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6X2KXXX | ||
| NxB06 | 7.5 | 230/3 | 150 | 24 | FNB06A6X3KXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6X4KXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6X2LXXX | ||
| NxB06 | 7.5 | 230/3 | 175 | 22 | FNB06A6X3LXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6X4LXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6U2HXXX | ||
| NxB04 | 5 | 230/3 | 100 | 22 | FNB04A6U3HXXX |
| NxB04 | 5 | 460/3 | FNB04A6U4HXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6U2JXXX | ||
| NxB04 | 5 | 230/3 | 125 | 20 | FNB04A6U3JXXX |
| NxB04 | 5 | 460/3 | FNB04A6U4JXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6U2KXXX | ||
| NxB04 | 5 | 230/3 | 150 | 17 | FNB04A6U3KXXX |
| NxB04 | 5 | 460/3 | FNB04A6U4KXXX | ||
| NxB04 | 5 | 230/1 | FNB04A6U2LXXX | ||
| NxB04 | 5 | 230/3 | 175 | 15 | FNB04A6U3LXXX |
| NxB04 | 5 | 460/3 | FNB04A6U4LXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6U2HXXX | ||
| NxB06 | 7.5 | 230/3 | 100 | 29 | FNB06A6U3HXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6U4HXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6U2JXXX | ||
| NxB06 | 7.5 | 230/3 | 125 | 27 | FNB06A6U3JXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6U4JXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6U2KXXX | ||
| NxB06 | 7.5 | 230/3 | 150 | 24 | FNB06A6U3KXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6U4KXXX | ||
| NxB06 | 7.5 | 230/1 | FNB06A6U2LXXX | ||
| NxB06 | 7.5 | 230/3 | 175 | 22 | FNB06A6U3LXXX |
| NxB06 | 7.5 | 460/3 | FNB06A6U4LXXX |
 |
| AIR COMPRESSOR PARTS |
 |
| AIR COMPRESSOR FILTERS |
 |
| AIR COMPRESSOR |
|
| AIR COMPRESSOR MOTOR REPAIR |
#FSCURTIS
#AIRCOMPRESSORSERVICE
 |
| ROTARY SCREW COMPRESSOR |
 |
| AIR COMPRESSOR SERVICE |
H&K AIR COMPRESSORS
214-428-2868
 |
| AIR COMPRESSOR SERVICE |
 |
| AIR COMPRESSOR REPAIR |
 |
| AIR COMPRESSOR TANKS |
LOOKING FOR ROTARY SCREW COMPRESSOR PARTS?
ROTARY SCREW SEPARATORS
ROTARY SCREW OIL
QUINCY ROTARY SCREW OIL
ATLAS COPCO ROTARY SCREW OIL
CURTIS ROTARY SCREW OIL
INGERSOLL RAND ROTARY SCREW OIL
ROTARY SCREW FILTERS
ROTARY SCREW TEMP. SENSORS
ROTARY SCREW PRESSURE SWITCHES
ROTARY SCREW MIN. PRESSURE VALVES
ROTARY SCREW BELTS
ROTARY SCREW HOSES
ROTARY SCREW MOTORS
ROTARY SCREW AIR ENDS
ROTARY SCREW CONTROL PANELS
ROTARY SCREW SENSORS
 |
| AIR COMPRESSOR SERVICE |
THE BEST RATED ROTARY SCREW COMPRESSORS ON THE MARKET WITH THE BEST
EXTENDED WARRANTY PROGRAM. CURTIS…#1 CUSTOMER SATISFACTION.
contact us for sales and service at: WWW.HKAIRCOMPRESSORS.COM
 |
| ROTARY SCREW COMPRESSOR SERVICE |
 |
| #AIRCOMPRESSORREPAIR |
 |
| AIR COMPRESSOR REPAIR |
 |
| LARGE INDUSTRIAL COMPRESSORS |
 |
| AIR COMPRESSOR SERVICE |
 |
| COMPRESSOR REPAIR |
 |
| ROTARY SCREW SERVICE |
 |
| AIR COMPRESSOR SERVICE |
 |
| AIR COMPRESSOR OIL |
 |
| AIR COMPRESSOR REPAIR |
 |
| #AIRCOMPRESSORSERVICE |
 |
| AIR COMPRESSOR SERVICE |
 |
| AIR COMPRESSOR SERVICE |
|
| INDUSTRIAL AIR COMPRESSORS |
No comments:
Post a Comment
